- Place of Origin: jinan
- Brand Name: yilin
- Model Number: JWM1325A
Product description
1, using imported linear square rails, double row and four column ball slider, loading capacity, smooth operation, high precision, long service life. Imported ball screw with high precision, accurate cutting tool.
2, software compatibility is good, can be compatible with a variety of CAD/CAM, such as type3/Artcam/Castmate/ design and production software.
Six, 3 partition vacuum adsorption mesa, can be effective for the adsorption of different sizes of plates. Vacuum pump can be selected to import the oil vacuum pump to solve the problem of water circulation vacuum pump in the cold weather.
4, using high-speed drive stepper motor and driver, Y axis adopts double motor drive, to make high-speed operation up to 35 m / min line speed of the air above, with vigorously cutting engraving spindle speed can be more improved.
Field of application
* the woodworking industry: three-dimensional wave board processing, cabinet doors, solid wood doors, wooden craft, paint free door, screen, craft window processing, shoe polisher, game cabinets and panels, mahjong table, computer aided machining table and panel furniture products.
People in other industries: various large relief carving, shadow carving, widely used in handicraft industry.
performance parameter
Performance index JWM1325A woodworking engraving machine
X, Y axis travel 1300 x 2500mm
Z axis stroke 200mm
Platform size 1480 * 3000mm
Maximum travel speed >25m/min
Clamping type suction clamp dual purpose
Engraving instructions *.u00*.mmg*.plt code G
Power (excluding spindle) 1.5KW
Working voltage 380V/50Hz AC
Spindle power 4.5KW (air cooled) / 5.5KW (water cooled)
Spindle speed 0-18000rpm/min / 24000rpm/min
Work way step
